Set Up and Configure a Cloud Environment in Google Cloud: Challenge Lab



Task - 1 : Create development VPC manually :-

gcloud compute networks create griffin-dev-vpc --subnet-mode custom

gcloud compute networks subnets create griffin-dev-wp --network=griffin-dev-vpc --region us-east1 --range=192.168.16.0/20

gcloud compute networks subnets create griffin-dev-mgmt --network=griffin-dev-vpc --region us-east1 --range=192.168.32.0/20

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 2 : Create production VPC manually :-

gsutil cp -r gs://cloud-training/gsp321/dm .

cd dm

sed -i s/SET_REGION/us-east1/g prod-network.yaml

gcloud deployment-manager deployments create prod-network \
    --config=prod-network.yaml

cd ..

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 3 : Create bastion host :-

gcloud compute instances create bastion --network-interface=network=griffin-dev-vpc,subnet=griffin-dev-mgmt  --network-interface=network=griffin-prod-vpc,subnet=griffin-prod-mgmt --tags=ssh --zone=us-east1-b

gcloud compute firewall-rules create fw-ssh-dev --source-ranges=0.0.0.0/0 --target-tags ssh --allow=tcp:22 --network=griffin-dev-vpc

gcloud compute firewall-rules create fw-ssh-prod --source-ranges=0.0.0.0/0 --target-tags ssh --allow=tcp:22 --network=griffin-prod-vpc

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 4 : Create and configure Cloud SQL Instance :-

gcloud sql instances create griffin-dev-db --root-password password --region=us-east1

gcloud sql connect griffin-dev-db

CREATE DATABASE wordpress;
GRANT ALL PRIVILEGES ON wordpress.* TO "wp_user"@"%" IDENTIFIED BY "stormwind_rules";
FLUSH PRIVILEGES;

exit

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 5 : Create Kubernetes cluster :-

gcloud container clusters create griffin-dev \
  --network griffin-dev-vpc \
  --subnetwork griffin-dev-wp \
  --machine-type n1-standard-4 \
  --num-nodes 2  \
  --zone us-east1-b


gcloud container clusters get-credentials griffin-dev --zone us-east1-b

cd ~/

gsutil cp -r gs://cloud-training/gsp321/wp-k8s .

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 6 : Prepare the Kubernetes cluster :-

// Open Editor -> wp-k8s -> wp-env.yaml
   Change username and password to :-
   username : wp_user
   password : stormwind_rules

// Save.

cd wp-k8s

kubectl create -f wp-env.yaml

gcloud iam service-accounts keys create key.json \
    --iam-account=cloud-sql-proxy@$GOOGLE_CLOUD_PROJECT.iam.gserviceaccount.com
kubectl create secret generic cloudsql-instance-credentials \
    --from-file key.json

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 7 : Create a WordPress deployment :-

// In editor : "wp-deployment.yaml" -> replace YOUR_SQL_INSTANCE with "griffin-dev-db".

// Save.

kubectl create -f wp-deployment.yaml
kubectl create -f wp-service.yaml

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 8 : Enable monitoring :-

// Navigation Menu -> Kubernetes Engine -> Services and Ingress -> Copy Endpoint's address.

// Navigation Menu -> Monitoring -> Uptime Checks -> + CREATE UPTIME CHECK
   Title : Wordpress Uptime
// Next -> Target
   Hostname : {Endpoint's address} (without http...)
   Path : /
// Next -> Next -> Create

----------------------------------------------------------------------------------------------------------------------------------------------

Task - 9 : Provide access for an additional engineer :-

// Navigation Menu -> IAM & Admin -> IAM -> ADD
   New Member : {Username 2 from Lab instruction page}
   Role : Project -> Editor

// Save.
